AA Multifix Tool Post + AaD1250 AaH1250 AaT Parting A0S1550 Drilling Tool Holder



Suitable for 120--220MM swing lathe. This is not a standard Aa kit.

(some customers name this model A0, SWH-AA or others). The tool post body is just a little bigger than a pingpang ball. This special Aa kit includes the following. 1 x Aa multifix tool post and locking wrench. 3 x AaD1250 turning tool holder.

1250 turning boring tool holder. 1250 parting off tool holder with 1 PC HSS 2X10X200MM parting off blade.

1 X A0S1550(Or AaJ1550) drilling tool holder. 1 x tool holder locking T wrench. Aa is about the smallest model made in China. Then A1(A), E5(E), B2(B), C3(C), D1(D), D2.

D2 is the biggest model. Aa can be installed on AT125.

For turning diameter is from 120mm to 220mm4.7. The Aa tool post can fit my 180mm(7) swing bench lathe well. From cross slide surface to spindle center line height is 56mm. Our Aa has sales in Israel, France, Russia, Thailand, Finland, USA, etc.
